Cubic industrial unit cooler OC/BC: Cubic CO2 and brine unit coolers

Cooling capacity from 10 kW to 275 kW

ENEX’s OC/BC cubic units are ideal for medium and large cold rooms requiring cooling and freezing applications. They can be used with a highly sustainable R744 direct expansion system or a brine loop.

Features

Finned coil: Built with grooved copper tubes (3/8” & 12mm Ø), and corrugated aluminium fins, manufactured according to CUPROCLIMA® specifications
Fans: Equipped as standard with AC fan motors.
Axial single-phase motors (230V I 50/60Hz)
Compliant with ErP Directive. Ø 500, 630, 800, 910 mm
Casing: Pre-painted aluminum, for high protection against corrosion even in extreme environmental conditions. Casing complies with the most stringent food hygiene standards
Design pressure: PS=60-80bar PT=86-115bar
